AUTOMATIC BIRD-HARVESTING
Product Series
New Style Broiler Cage For Automatic Poultry Farming Equipment Chicken House Animal & Poultry Husbandry Equipment Battery
The frame of cage is formed with the hot galvanized plate by using CNC machine,Accurate assembling can improve the stability of the cage structure,also avoid manure belt off running.
Keywords:
Classification:
Broiler Cage System
NEW STYLE N9LRC3132
In recent years, the poultry farming industry has witnessed significant advancements in technology and equipment, leading to improved efficiency and productivity. As the global demand for poultry products continues to rise, farmers are increasingly seeking innovative solutions to optimize their operations. One such innovation is the introduction of new style broiler cages, designed specifically for automatic poultry farming. These modern cages not only enhance the living conditions for chickens but also streamline the overall management of poultry houses. With features aimed at maximizing space utilization, improving hygiene, and facilitating easy access for feeding and maintenance, these advanced broiler cages represent a pivotal shift in animal husbandry practices. This article explores the benefits and functionalities of these new broiler cages, highlighting their role in shaping the future of poultry farming.
NEW STYLE 9LRC-3081
MANUAL BIRD-HARVESTING
The frame of cage is formed with the hot galvanized plate by using CNC machine,Accurate assembling can improve the stability of the cage structure,also avoid manure belt off running.
Quantity Of Broiler
Model | Width(mm) | Square Of Cage(mm²) | Distance Of Two Legs(mm) | Length Of Unit(mm) | Quantiy Of Broiler | |||
3kg | 2.5kg | 2kg | 1.5kg | |||||
9LRC3081 | 950 | 1400×950 | 1400 | 1400 | 22 | 27 | 33 | 44 |
Bottom of trough is changed to V-shape,more suitable for bird's eating habits;the feed is distributed more uniformly,that effectively prevent the moldy feed and ensure the broilers to eat fresh feed,also greatly reduce waste of feed.
A lower connector of cage is enhanced to stamp it,convenient to observe and take birds.The doors adopt push-in style,easy to operate.
New type of feeding trolley keep running along the guide rail that placed on the floor.Independent trolley design make it run smoothly and no noise.A big section of discharge ensure feed not blocked in it.The new distributor also can ensure feed uniformly in the trough and can be adjusted,to avoid the waste of feed.
The bird\manure two-in-one conveyor removes manure normally,at the end of broiler final,then can be lifted tier by tier to remove birds to disc machine,via a removable bird-conveying machine.
With two conveyors,the one is for manure,the one is for final birds,when harvesting birds,At the end of battery cages,workers load the birds into box directly.Then through the conveyor transport to the truck outsides.This can reduce the transfer of chicken in process of the harvest,greatly reducing the chicken's disability.
The surface of driving rolls is integrally coated with rubber,thus increasing friction,solving the problem about manure belt off-tracking,extending the belt service life.
One scraper is installed at the end of manure belt,and two secondary scrapers are installed below returning belt,so that manure can be cleared thoroughly.
Chains are used for tensioning belt,also can be convenient to adjust.
Each tier manure is conveyed to the end via a manure bel,falls onto the cross manure belt and finally is conveyed to a manure truck outside poultry house via the elevating manure belt.
Periodical manure clearing improves the rearing environment and reduces the occurrence of diseases.
